FIAMM AGM Battery for solar panels 27 Ah FG22703

Reference: FG22703

Condition: New product

By buying this product you can collect up to 6 loyalty points. Your cart will total 6 loyalty points that can be converted into a voucher of 0,30 €.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Send to a friend

Send to a friend

FIAMM AGM Battery for solar panels 27 Ah FG22703

Recipient :

Name of your friend ^* :

E-mail address of your friend ^* :

^* Required fields

or Cancel
Print

Data sheet

Height (inches)	125 mm
Width	166 mm
thickness (mil)	175 mm
Weight (Oz)	8500 g
Capacity	27 Ah 20 hours rate to 1.75 Vpc at 25 °C
Nominal Voltage	12 V

More info

FIAMM AGM Battery for solar panels 27 Ah FG22703

FIAMM batteries of the FG series are lead-acid batteries regulated by valve that ensures maximum reliability without requiring any maintenance.
Made with AGM technology, with absorbed electrolyte of the glass fibers, represent an ideal solucione for a fixed or mobile use, in combination with a 12V photovoltaic system.

The main feature is the total absence of maintenance, thanks to an internal chemical process of recombination of the elements on the alloy Pb-Ca plates which also ensures a low self-discharge, and a good operation of temperature excursions between -20 ° C and + 50 ° C
The hermetic construction guarantees the absence of electrolyte leakage and thus allows a safe use of the battery at any position.

Dettagli tecnici sono nel datasheet allegato.

FIAMM batteries Technical Features
Article	Description (battery)	Dim. (LxPxA) (mm)
FG10301	6V-3,0Ah con terminale faston 4,8	134x34x65
FG10381	6V-3,8Ah con terminale faston 4,8	66x33x122
FG10451	6V-4,5Ah con terminale faston 4,8	70x48x106
FG11201	6V-12Ah con terminale faston 4,8	151x50x99
FG20086	12V-0,8Ah con connettore	96x25x61,5
FG20121	12V-1,2Ah con terminale faston 4,8	97x48,5x55
FG20201	12V-2,0Ah con terminale faston 4,8	178x34x65
FG20301	12V-3Ah con terminale faston 4,8	134x68x63
FG20722	12V-7,2Ah con terminale faston 6,3	151x65x99
FG20451	12V-4,5Ah con terminale faston 4,8	90x70x105
FG20721	12V-7,2Ah con terminale faston 4,8	151x65x99
FG21202	12V-12Ah con terminale faston 4,8	151x98x99
FG22703	12V-27Ah terminale a vite/bull. M5	166x125x175
FG21803	12V-18Ah terminale a vite/bull. M6	181x76x167
FG24204	12V-42Ah terminale a vite/bull. M6	196x163x174
FG27004	12V-70Ah terminale a vite/bull. M6	350x166x174

Lead Acid Rechargeable

	Please read the user manual before proceeding to installation of the product.
	For safety reasons, carefully follow the instructions about precautions given in the battery user manual for installing
